The 30mm sheave series 1 block range with its stainless steel frame for added strength is available in both plain and ball bearing options. Modern design, high strength, lghtweight features allow for a multitude of uses on every size of craft.
| Ref | Ø Sheave |
Sheave Width |
Ø Max Rope |
SWL | Break Load |
Length |
| N01110 | 30 mm | 11 mm | 8 mm | 350 Kg | 700 Kg | 70 mm |
| N02110 | 35 mm | 11 mm | 8 mm | 370 Kg | 740 Kg | 65 mm |
| N03110 | 45 mm | 13 mm | 10 mm | 400 Kg | 800 Kg | 80 mm |
| N05110 | 54 mm | 17 mm | 12 mm | 750 Kg | 1500 Kg | 107 mm |
| N06110 | 64 mm | 18 mm | 12 mm | 1000 Kg | 2000 Kg | 118 mm |
| N07110 | 70 mm | 20 mm | 14 mm | 1250 Kg | 2500 Kg | 137 mm |
