● This cleat is perforated at the bottom so that the closures are not visible, except for the TAURUS06 and 07, which have 4 fixing holes for the M12 screws whose bolt heads are visible.
● Made of stainless steel (AISI 316), high-gloss polished.
| Referencia | SWL* | A | B | C | D | E |
| TAURUS01 | 575 kgf | 140 | 50 | 89.5 x 30 | 47 | 2 x M8 |
| TAURUS02 | 900 kgf | 195 | 60 | 120.5 x 35 | 69 | 2 x M10 |
| TAURUS03 | 1310 kgf | 255 | 75 | 150 x 40 | 83 | 2 x M12 |
| TAURUS04 | 2470 kgf | 300 | 85 | 160 x 50 | 83 | 2 x M16 |
| TAURUS05 | 2470 kgf | 300 | 85 | 200 x 85 | 83 | 2 x M8 |
| TAURUS06 | 2620 kgf | 300 | 85 | 200.5 x 85 | 130 x 55 | 4 x Ø12.5 |
| TAURUS07 | 3600 kgf | 250 | 70 | 250 x 40 | 105 | 3 x Ø12.5 |
*SWL= Maximum safety load
** 4 holes in a rectangle according to dimension D. The holes are countersunk 90º
*** 3 holes in a row with 105m between them. The holes are countersunk 90º
