● Use to Sinumax technology wnsuring the necessary power but with limited weight and size.
● Sinumax is also compatible with power peaks during the starting phase required by devices such as refrigerators, electric motors and similar, while traditional switching inverters don't manage these peaks in an optimum way.
● Technical features:
● Aluminium frame.
● Forced ventilation with temperature sensor
● Protections for short circuit, overload, high or low battery voltage with alarm, high temperature.
|
Code
|
V
|
Type | Outlet Socket | V | Hertz | Range (W) | Efficiency % | Dimensions (mm) | Weight (Kg) | ||
| DC intlet V | AC outlet V | Continuous | Peak | ||||||||
|
14.270.07
|
12 | 12/1200 direct | Schuko | 9.2-17.3 | 230+-3% | 50 | 1200 | 2400 | 92 | 104x194x305 | 8.5 |
|
14.270.16
|
12
|
12/250 direct | Schuko | 9.2-17.3 | 230+-3% | 50 | 250 | 350 | 87 | 86x165x260 | 2.4 |
|
14.270.17
|
24
|
12/375 direct | Schuko | 18.4-34 | 230+-3% | 50 | 250 | 350 | 90 | 86x165x260 | 2.4 |
|
14.270.18
|
12
|
500 direct | Schuko | 10.5-15.5 | 230+-3% | 50 | 500 | 1000 | 91 | 86x172x275 | 3.9 |
|
14.270.19
|
24
|
500 direct | Schuko | 21-31 | 230+-3% | 50 | 500 | 1000 | 91 | 86x172x275 | 3.9 |
|
14.270.20
|
12
|
12/375 direct | Schuko | 9.2-17.3 | 230+-3% | 50 | 375 | 700 | 89 | 86x165x260 | 3 |
|
14.270.21
|
24 | 24/375 direct | Schuko | 18.4-34 | 230+-3% | 50 | 375 | 700 | 89 | 86x165x260 | 3 |
|
14.270.22
|
12
|
12/800 direct | Schuko | 9.2-17.3 | 230+-3% | 50 | 800 | 1600 | 90 | 105x216x305 | 5.5 |
|
14.270.23
|
24
|
24/800 direct | Schuko | 18.4-34 | 230+-3% | 50 | 800 | 1600 | 90 | 105x216x305 | 5.5 |
|
14.270.48
|
24
|
24/1200 direct | Schuko | 18.4-34 | 230+-3% | 50 | 1200 | 2400 | 94 | 117x232x327 | 7.4 |
